Ingiant Non-standard custom high-end precision slip ring for aviation plug

Core Product Features & Buyer Benefits

• Full Customization to Meet Diverse Needs: Both the number of circuits and rated current can be customized according to the specific requirements of the buyer’s equipment, avoiding the waste of resources caused by mismatched standard products. The wire length is 500mm±20mm, and can be further adjusted according to the installation space of the equipment, ensuring perfect fit with the buyer’s existing system and reducing the cost of secondary modification.
• Aerospace Connector Design for Easy Installation & Replacement: Both rotor and stator are equipped with aerospace connectors, which not only ensure exclusive connection with the equipment, improve the stability and reliability of equipment operation, but also simplify the installation and replacement process. For professional buyers, this design reduces the time cost of equipment maintenance and replacement, and shortens the downtime of key equipment.
• High Precision & Strong Anti-Vibration Performance: With extremely high design precision, it can fully meet the anti-vibration requirements during equipment operation, especially suitable for high-vibration scenarios such as tanks, armored vehicles and helicopters. It effectively avoids signal interruption or equipment failure caused by vibration, ensuring the continuous and stable operation of the buyer’s equipment in complex working conditions.
• Wide Temperature Adaptability & Harsh Environment Resistance: The working temperature ranges from -40℃ to +65℃, which can adapt to high and low temperature environments in different regions and scenarios. The working humidity is less than 70%, and the protection level reaches IP54, which can effectively prevent dust and splashing water from entering the product, ensuring stable operation in harsh environments such as field operations and marine navigation.
• Strong Anti-Interference & High-Quality Signal Transmission: It has strong anti-interference ability, which can stably transmit weak signals such as sensor signals in harsh environments without signal distortion or loss. For professional buyers who need to transmit precise signals (such as radar and sensor equipment), this feature ensures the accuracy of equipment data collection and analysis, helping them make correct decisions.
• Durable & Low Maintenance Cost: Adopting precious metal electrical contact materials, it has strong overload capacity, low wear, long service life and low maintenance demand. At the same time, the wear dust is small, which avoids equipment failure caused by dust accumulation and reduces the maintenance frequency and cost of the buyer’s equipment, improving the overall operational efficiency of the equipment.
• Excellent Electrical Performance & Safety: The insulation resistance is ≥1000MΩ (under 500V DC), and the insulation strength reaches 1500V AC, 50Hz, lasting 60 seconds, with a leakage current of only 2mA, ensuring the safety of electrical operation. The dynamic resistance change value is less than 10mΩ, ensuring stable current and signal transmission, and avoiding equipment damage caused by electrical performance problems.
• High-Quality Materials & Reliable Quality: The shell is made of aluminum alloy, which is light in weight, high in strength and good in corrosion resistance, suitable for long-term use in complex environments. The wires adopt color-coded PTFE insulated tinned multi-strand soft wires, which have good insulation performance, high temperature resistance and flexibility, and are not easy to break, ensuring the reliability of the product during long-term operation.

Detailed Technical Parameters

Typical Applications

• Ground Defense Equipment: Tanks, armored vehicles, etc.
• Aerospace Equipment: Helicopters, etc.
• Electronic Equipment: Radar, radar turntables, etc.
• Industrial Equipment: Robots, etc.
• Marine Equipment: Ship propulsion systems, etc.

Why Choose Our Slip Ring?

• Customization Capability: Fully customized according to the buyer’s equipment requirements, ensuring perfect matching and avoiding resource waste.
• High Reliability: Adopting high-quality materials and precise manufacturing, with long service life and low maintenance cost, reducing the total cost of ownership for buyers.
• Strong Environmental Adaptability: Suitable for high and low temperature, high humidity, high vibration and other harsh environments, ensuring stable operation of equipment in complex scenarios.
• High-Quality Transmission: Strong anti-interference ability and stable electrical performance, ensuring the accuracy and continuity of signal and power transmission.
• Easy Installation & Maintenance: Aerospace connector design simplifies the installation and replacement process, reducing the time cost and labor cost of buyers.
