Ingiant Network HD Ethernet slip ring large pore size through hole slip ring
|
DHK120-25 |
|||
|
The main parameters |
|||
|
Number of circuits |
25 |
Working temperature |
“-40℃~+65℃” |
|
Rated current |
2A.5A.10A.15A.20A |
Working humidity |
＜70% |
|
Rated voltage |
0~240 VAC/VDC |
Protection level |
IP54 |
|
Insulation resistance |
≥1000MΩ @500VDC |
Housing material |
Aluminum Alloy |
|
Insulation strength |
1500 VAC@50Hz,60s,2mA |
Electrical contact material |
Precious metal |
|
Dynamic resistance variation |
＜10MΩ |
Lead wire specification |
Colored Teflon insulated & tinned stranded flexible wire |
|
Rotating speed |
0~600rpm |
Lead wire length |
500mm + 20mm |
Standard product outline drawing:
DHK120-25 network high-definition slip ring is a standard through-hole slip ring and Ethernet combination product, providing 25 transmission channels (the number of channels can be expanded), 10A/channel transmission power or signal and combined Ethernet communication; used for 10 / 100BaseT Ethernet This type of Ethernet communication.
The Ethernet cable provides two connection methods with Rj45 jack and Cat line for convenient connection. For transmitting high-definition video, high-speed digital and other signals. Standard Ethernet slip rings include solid shaft Ethernet and through-hole Ethernet, which have the characteristics of stable transmission, no packet loss, no aliasing, low return loss, low insertion loss, and long life.
Features
- Modular design to meet higher current, speed, appearance and other needs
- ETHERNET is fully compatible with IEE 802.3 format; provided with RJ45 jack
- 10BaseT –100BaseTx –100BaseT2 –1000BaseT
- Supports transmission of power and data signals and high-speed digital signal mixed transmission
Our Advantage
- Product advantage: Cost effective,High quality,IP protection rated,Suitable for extreme environments, Explosion proof units, High reliability low maintenance, Integration of high frequency channels , Standard units and custom design, Transmission of high definition video with high frame rate, 360 degree continuous panning, Integration of rotary joints and Ethernet, Fully gimbaled systems, Twist capsule integration ,Long life.
- Company advantage: More than 10 years experienced senior engineers in the industry and 12 people R&D team, provide more professional and reliable solutions for your rotating conduction problems. More than 60 workers with several years experience in workshop production, skilled in operation and production, can better guarantee product quality. Depending on strong R&D ability and close cooperation with well-know enterprises & research institutes, Ingiant could not only provide standard industrial slip rings, but also customize different slip rings according to customer’s different requirements.
- Excellent after-sales and technical support service, by providing high-quality products and technical services, Ingiant has a live, rich experience team can response your requests when you reach out to us for after-sales and techinical support service request.
