Ingiant 80mm Through Hole Slip Ring For EV Charger

Short Description:

Product Detail

Product Tags

Product Description

Ingiant is a professional customized slip ring manufacturer in China.
Ingiant slip ring is use for rotating transfer electric signal/power/data, solve wire winding problems.
It also can be combined with pneumatic and hydraulic rotary joints.

Ingiant DHK080F-6-40A slip ring is made with IP65, function waterproof and dust proof, the item is customized for EV charger, function is for rotating transfer large current.

80mm through hole is our standard size, normally standard size product use engineering plastic structure and aluminum alloy housing material for production, but we can upgrade the material per customer’s requirements, for IP65 protection level, engineering plastic structure material is not enough for the sealing requirement, we will need to upgrade it to stainless steel or aluminum alloy material.



The main parameters

Number of circuits 6 channels Working temperature “-40℃~+65℃"
Rated current 2A,5A,10A,15A,20A Working humidity <70%
Rated voltage 0~240 VAC/VDC Protection level IP65
Insulation resistance ≥1000MΩ @500VDC Housing material Aluminum Alloy
Insulation strength 1500 VAC@50Hz,60s,2mA Electrical contact material Precious metal
Dynamic resistance variation <10MΩ Lead wire specification Colored Teflon insulated & tinned stranded flexible wire
Rotating speed 0~600rpm Lead wire length 500mm + 20mm


The slip ring has very good sealing performance for water proof and dust proof, structure material made with aluminum alloy, very durable and long working lifespan.

Precious metal electrical contact, make the power and signal transfer very stable.

Ingiant own 6000 square meters of factory building, CNC workshop, mature R&D team, full sets of test equipment, make sure every piece of product 100% meet with quality standard, and provide the most professional solution for your rotating transfer signal/power/data & gas/liquid!

We provide 12 months of warranty for the product!

Slip ring application area is very widely: such as ROV, EV charger, packing machine, robot, cable reel, cleaning equipment, rotary light, mold equipment, woven equipment, cutting equipment, rotary testing equipment, agriculture silo, radar, wind power, etc.
