Low Speed Rotary Joint 2RPM Water Media Brass Stainless Steel Rotary Union

Low Speed Rotary Joint 2RPM Water Media Brass Stainless Steel Rotary Union Featured Image
  • Low Speed Rotary Joint 2RPM Water Media Brass Stainless Steel Rotary Union

Short Description:

Model: TEDHD-25

Materials：Housing: brass
Shaft: stainless steel

This rotary union is specially designed for cooling drum applications using cold water. It runs stably under low speed and low pressure conditions, with reliable sealing and long service life.


Product Detail

Product Tags

TEDHD-25 Rotary Union for Cooling Drum Brass Stainless Steel Water Rotary Joint

Operating Conditions

  • Medium: cold water (not lower than 4°C)
  • Outlet water pressure: 1.5–2 bar
  • Max. rotation speed: 2 rpm
  • Thread: G 3/4 (right & left-hand), G 1 1/4 (right & left-hand)
