30 Circuits Wind Turbine Pitch Slip Ring, 5×80A 400VAC Power + Signal Hybrid Rotary Joint, IP65 for 2-3MW Wind Turbines

Short Description:

FHS135-30-30332 Hybrid Pitch Control Slip Ring for Wind Turbines

Model: FHS135-30-30332 Wind Turbine Pitch Slip Ring.
Hybrid Design: Integrates 5 circuits of 80A/400VAC power with 25 circuits of control & shielded signals.
Rugged Build: IP65 protection and -40°C to +80°C wide operating range for harsh environments.
Premium Contact: Precious metal contacts with beryllium copper brushes; dynamic resistance <10mΩ.
Modular Service: Independent power/signal rings allow on-site replacement, reducing O&M costs.
Compatibility: Customizable for 2.0–3.0MW turbines (Goldwind, Sinovel, Mingyang, etc.).

Product Detail

Product Tags

FHS135-30-30332 Hybrid Pitch Control Slip Ring for Wind Turbines

In wind turbine applications, the pitch slip ring is the critical link that transmits power and control signals from the stationary nacelle to the rotating hub, enabling real-time blade pitch adjustment for optimal energy capture and emergency feathering. Our FHS135-30-30332 is purpose-engineered for 2.0–3.0 MW class wind turbines, integrating high-power transmission and low-noise signal communication into a single ruggedized unit.

Key Features

Hybrid Power & Signal Transmission — 5 circuits × 80A @ 400VAC for pitch motor driving, plus 25 auxiliary power, control and shielded communication circuits (CANBus / Profibus compatible)
Industrial-Grade Durability — IP65 protection with -40°C to +80°C operating range, resistant to dust, salt mist, and extreme vibration
Premium Contact System — Precious metal plated rings with beryllium copper brush wires; dynamic resistance variation <10 mΩ for ultra-stable signal integrity
Modular & Serviceable — Power rings and signal rings are independently replaceable, dramatically reducing O&M downtime and cost
Anti-EMI Design — Physically isolated power/signal routing prevents electromagnetic interference, ensuring zero packet loss on communication rings
Heavy-Duty Connectors — Harting-style industrial connectors on both rotor and stator sides for secure, tool-free maintenance

Technical Specifications

Parameter	Specification
Model	FHS135-30-30332
Type	Wind Turbine Pitch Control Slip Ring
Circuits	30 channels
Current Rating	5× 80A (400VAC) + 2× 25A (230VAC) + 10× 5A (250VAC) + 8× 5A (24VDC) + 2× 2A (24VDC, 1 shielded)
Voltage Rating	0–400VAC / 240VDC (main); 500VAC / 240VDC (aux.)
Insulation Resistance	≥ 1000 MΩ @ 1000VDC
Dielectric Strength	2500VAC @ 50Hz/60s (main); 1500VAC @ 50Hz/60s (others)
Dynamic Resistance	< 10 mΩ
Operating Speed	0–30 RPM
Operating Temperature	-40°C to +80°C
Protection Grade	IP65
Starting Torque	< 0.05 N·m
Housing Material	Aluminum alloy / Beryllium copper / Chrome steel
Contact Material	Precious metal
Connectors	Harting-style heavy-duty (both ends)

Application Scenarios

2.0–3.0 MW Onshore Wind Turbines — Compatible with Goldwind, Sinovel, Dongfang Electric, Mingyang, Envision
Coastal & Highland Wind Farms — IP65 + -40°C cold-resistant variant available
Radar & Antenna Rotary Systems — Where hybrid power + high-speed data transmission is required
Large Rotating Machinery — Crane, tunnel boring machine, cable reel applications
