DHK176 series large inner hole 176mm through hole slip ring

• Through Hole Slip Rings – DHK large inner hole Series

Available for custom, standard ID 3-500 mm, OD 10-800 mm

DHK176-29 series large-bore through-hole slip rings feature an inner bore of 176mm and an outer diameter of 290mm. They are suitable for rotating electromechanical systems with a diameter less than 176mm. Power loops are 5A or 10A per ring, with a 4-ring design and a signal loop of 2A per ring, with a 25-ring design. They are designed to transmit power or signals in 360-degree rotating systems. They can be used in automated industrial control systems, automated electrical transmission systems, and intelligent filling robots.

• Typical Applications:

Cable manufacturing equipment, metal surface finishing machinery, automated systems, factory production lines, offshore oil platforms, coal terminal dedicated equipment, ​and any devices requiring 360° rotating conductive connections or transmission of various control signals.​

• Product Naming Description

(1)Product type: DH—electric slip ring
(2)Installation method: K—through hole
(3)Through hole product bore diameter10 mm
(4)Total circuits:16 circuits
(5)The rated current or it will not be marked if it passes through a different rated current for the circuits.

(6) Identify number: –XXX; In order to distinguish different specifications of the same product model, the identification number is added after the name. For example: DHK080-24 has two sets of products with the same name, the cable length, connector, installation method, etc. are different, you can add the identification number: DHK080-24-002; if there are more of this model in the future, and so on -003 , -004, etc.
• DHK176-29 Through Bore Slip Ring Technical Parameters
