DHK008-5 Mini inner hole 8mm through hole slip ring

• Through Hole Slip Rings – DHK mini inner hole Series

Available for custom, standard ID 3-500 mm, OD 10-800 mm

DHK008-5 series through-hole conductive slip rings with an 8mm bore are suitable for rotating electromechanical systems with a bore diameter less than 8mm. They are rated at 2A/ring and have 5 rings. The housing is made of aluminum alloy, with options for special engineering plastics or stainless steel.

For stable transmission of power or signals in electromechanical systems that require 360 degree rotation, it can also be designed in combination with cyclone adapters, liquid rotary adapters, fiber optic slip rings, etc. to form a multifunctional hybrid slip ring.

• Typical Applications:

Applications include winding machines, laser scanners, in-pipe cameras, exhibition/display equipment, food vending machine slip rings, CCD visual inspection equipment, intelligent vision systems, automated assembly machines, rotating LED lights, labeling machines, laboratory equipment, biological testing instruments, and any other device requiring 360-degree rotation, conducting electricity, or transmitting various control signals.

• Product Naming Description

(1)Product type: DH—electric slip ring
(2)Installation method: K—through hole
(3)Through hole product bore diameter10 mm
(4)Total circuits:16 circuits
(5)The rated current or it will not be marked if it passes through a different rated current for the circuits.

(6) Identify number: –XXX; In order to distinguish different specifications of the same product model, the identification number is added after the name. For example: DHK080-24 has two sets of products with the same name, the cable length, connector, installation method, etc. are different, you can add the identification number: DHK080-24-002; if there are more of this model in the future, and so on -003 , -004, etc.
• DHK08-5 Through Bore Slip Ring Technical Parameters
