DHK007 mini inner hole 7mm through hole slip ring

• Through Hole Slip Rings – DHK mini inner hole Series

Available for custom, standard ID 3-500 mm, OD 10-800 mm

DHK007-58-3A series mini through-hole conductive slip rings have a 7mm bore and are suitable for rotating electromechanical systems with a bore diameter less than 7mm. They are 3A/ring and have 58 rings. The housing is made of aluminum alloy, with optional special engineering plastics or stainless steel.

For stable transmission of power or signals in electromechanical systems that require 360 degree rotation, it can also be designed in combination with cyclone adapters, liquid rotary adapters, fiber optic slip rings, etc. to form a multifunctional hybrid slip ring.

• Typical Applications:

Widely used in intelligent vision robots, packaging machines, filling machines, cutting machines, sampling machines, small amusement machines and other automation equipment.

• Product Naming Description

(1)Product type: DH—electric slip ring
(2)Installation method: K—through hole
(3)Through hole product bore diameter10 mm
(4)Total circuits:16 circuits
(5)The rated current or it will not be marked if it passes through a different rated current for the circuits.

(6) Identify number: –XXX; In order to distinguish different specifications of the same product model, the identification number is added after the name. For example: DHK080-24 has two sets of products with the same name, the cable length, connector, installation method, etc. are different, you can add the identification number: DHK080-24-002; if there are more of this model in the future, and so on -003 , -004, etc.


• DHK010-16-002 Through Bore Slip Ring Technical Parameters
