2 Channels carbon brush slip ring traditional collector slip ring

Carbon brush slip rings are key components in rotating equipment designed for the continuous transmission of energy and signals, primarily composed of carbon brushes and slip rings (collecting rings).

Carbon brushes are typically fabricated from graphite, impregnated graphite, or metal graphite, mounted on the surface of commutators or collecting rings, and transmit current from stationary parts to rotating components via sliding contact.

Technical Features:​​

• Exceptional electrical conductivity and extended service life;
• Smooth brush operation with reliable sliding contact, characterized by absence of overheating, noiseless performance, and low energy loss;
• During operation, the slip ring maintains a uniformly distributed, moderately conditioned, and stable surface;
• Each carbon brush is subjected to uniform and stable pressure, with the structural design ensuring brush stability and consistent contact;
• Capable of stably transmitting both signals and currents during operation.

Technical Parameter
